MIC2941AWU-TR 数据手册
其他文档
MIC2940A/2941A 24 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC2941AWU-TR
- Output Type: Adjustable
- Output Current: 1.25A
- Output Voltage: 1.24V~26V
- Dropout Voltage: 600mV@(1.25A)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 26V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 500uA
- Power Supply Rejection Ratio (PSRR): -
- Package: TO-263-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 26V
- Voltage - Output (Min/Fixed): 1.24V
- Voltage - Output (Max): 26V
- Voltage Dropout (Max): 0.6V @ 1.25A
- Current - Output: 1.25A
- Current - Quiescent (Iq): 500µA
- Current - Supply (Max): 70mA
- PSRR: -
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Reverse Polarity
- Mounting Type: Surface Mount
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Supplier Device Package: TO-263-5
- Base Part Number: MIC2941A
- detail: Linear Voltage Regulator IC 1 Output 1.25A TO-263-5
