Analog and Interface Product Guide دیتاشیت

Analog and Interface Product Guide

مشخصات دیتاشیت

نام دیتاشیت Analog and Interface Product Guide
حجم فایل 4947.971 کیلوبایت
نوع فایل pdf
تعداد صفحات 76

مشاهده دیتاشیت Analog and Interface Product Guide

دانلود دیتاشیت

سایر مستندات

MICROCHIP TC7662BCPA 11 pages

TC7662B 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: -
  • Topology: -
  • Datasheet: Microchip Tech TC7662BCPA
  • Output Type: Fixed
  • Input Voltage: 1.5V~15V
  • Output Voltage: -15V~-1.5V
  • Number of Outputs: 1
  • Switching Frequency: 35kHz
  • Output Current (Max): 20mA
  • Operating Temperature: 0°C~+70°C@(TA)
  • Synchronous Rectification: NO
  • Package: DIP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive or Negative
  • Voltage - Input (Min): 1.5V
  • Voltage - Input (Max): 15V
  • Voltage - Output (Min/Fixed): -Vin, 2Vin
  • Voltage - Output (Max): -
  • Current - Output: 20mA
  • Frequency - Switching: 10kHz ~ 35kHz
  • Synchronous Rectifier: No
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC7662B
  • detail: Charge Pump Switching Regulator IC Positive or Negative Fixed -Vin, 2Vin 1 Output 20mA 8-DIP (0.300", 7.62mm)
