دیتاشیت MIC4422YN
مشخصات دیتاشیت
| نام دیتاشیت | MIC4421, MIC4422 |
|---|---|
| حجم فایل | 241.53 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MIC4421, MIC4422 |
MIC4421, MIC4422 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: Microchip Tech MIC4422YN
- Fall Time: 24ns
- Load Type: IGBT;MOSFET
- Rise Time: 20ns
- Supply Voltage: 4.5V~18V
- Number of Drivers: 1
- Driven Configuration: Low Side
- Operating Temperature: -40°C~+150°C@(Tj)
- Peak Output Current(sink): 9A
- Peak Output Current(source): 9A
- Package: DIP-8
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Channel Type: Single
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 4.5V ~ 18V
- Logic Voltage - VIL, VIH: 0.8V, 2.4V
- Current - Peak Output (Source, Sink): 9A, 9A
- Input Type: Non-Inverting
- Rise / Fall Time (Typ): 20ns, 24ns
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: MIC4422
- detail: Low-Side Gate Driver IC Non-Inverting 8-PDIP
