MCP23017, MCP23S17 Datasheet دیتاشیت

MCP23017, MCP23S17 Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCP23017, MCP23S17 Datasheet
حجم فایل 865.289 کیلوبایت
نوع فایل pdf
تعداد صفحات 42

دانلود دیتاشیت MCP23017, MCP23S17 Datasheet

دانلود دیتاشیت

سایر مستندات

MCP23S17 Rev A Errata 6 pages

MCP23S17T-E/SO 42 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/I/O Expanders
  • Datasheet: Microchip Tech MCP23S17-E/SP
  • Interface: SPI
  • Output Type: Push-pull
  • Number of I/O: 16
  • Supply Voltage: 1.8V~5.5V
  • Clock Frequency: 10MHz
  • Interrupt Output: 有中断输出
  • Output Sink Current: 25mA
  • Operating Temperature: -40°C~+125°C
  • Output Source current: 25mA
  • Package: DIP-28
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Features: POR
  • Current - Output Source/Sink: 25mA
  • Voltage - Supply: 1.8V ~ 5.5V
  • Mounting Type: Through Hole
  • Package / Case: 28-DIP (0.300", 7.62mm)
  • Supplier Device Package: 28-SPDIP
  • Base Part Number: MCP23S17
  • detail: I/O Expander 16 SPI 10MHz 28-SPDIP
