LM3502 Datasheet
Datasheet specifications
| Datasheet's name | LM3502 |
|---|---|
| File size | 1407.034 KB |
| File type | |
| Number of pages | 28 |
Download Datasheet LM3502 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Part Status: Obsolete
- Number of Outputs: 2
- Current - Output / Channel: 600mA (Switch)
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply (Min): 2.5V
- Frequency: 1MHz
- Packaging: Tape & Reel (TR)
- Series: -
- Internal Switch(s): Yes
- Type: DC DC Regulator
- Applications: Backlight
- Voltage - Output: 25V
- Manufacturer: Texas Instruments
- Topology: Step-Up (Boost)
- Dimming: PWM
- Base Part Number: LM3502
- Package / Case: 10-WFBGA, DSBGA
- Mounting Type: Surface Mount
- Supplier Device Package: 10-TµSMD (1.9x2.07)
- Voltage - Supply (Max): 5.5V
- detail: LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) PWM Dimming 600mA (Switch) 10-TµSMD (1.9x2.07)
