دیتاشیت ADP3050ARZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP3050
|
| حجم فایل |
355.973
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Function:
Step-Down, Step-Up/Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck, Buck-Boost, SEPIC
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
3.6V
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
1.25V
-
Voltage - Output (Max):
12V
-
Current - Output:
1A (Switch)
-
Frequency - Switching:
200kHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
ADP3050
-
detail:
Buck, Buck-Boost, SEPIC Switching Regulator IC Positive Adjustable 1.25V 1 Output 1A (Switch) 8-SOIC (0.154", 3.90mm Width)
