INA131AP-1G4 Datasheet
Datasheet specifications
| Datasheet's name | INA131 |
|---|---|
| File size | 123.913 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet INA131 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Part Status: Obsolete
- Output Type: -
- Current - Output / Channel: 20mA
- Operating Temperature: -40°C ~ 85°C
- Slew Rate: 0.7V/µs
- Packaging: Tube
- Series: -
- Voltage - Supply, Single/Dual (±): 4.5V ~ 36V, ±2.25V ~ 18V
- Current - Input Bias: 500pA
- Voltage - Input Offset: 25µV
- -3db Bandwidth: 70kHz
- Manufacturer: Texas Instruments
- Current - Supply: 2.2mA
- Number of Circuits: 1
- Base Part Number: INA131
- Package / Case: 8-DIP (0.300", 7.62mm)
- Mounting Type: Through Hole
- Supplier Device Package: 8-PDIP
- Amplifier Type: Instrumentation
- detail: Instrumentation Amplifier 1 Circuit 8-PDIP
