ADM8832 Datasheet
Datasheet specifications
|
Datasheet's name
|
ADM8832
|
|
File size
|
912.808
KB
|
|
File type
|
pdf
|
|
Number of pages
|
12
|
Technical specifications
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Part Status:
Obsolete
-
Main Purpose:
Special Purpose DC/DC, LCD Supply
-
Outputs and Type:
3, Non-Isolated
-
Voltage - Output:
5.1V, 15.3V, -10.2V
-
Current - Output:
5mA, 1µA, 1µA
-
Voltage - Input:
2.6V ~ 3.6V
-
Regulator Topology:
Boost
-
Frequency - Switching:
100kHz
-
Board Type:
Fully Populated
-
Supplied Contents:
Board(s)
-
Utilized IC / Part:
ADM8832
-
Base Part Number:
ADM8832
-
detail:
ADM8832 - Special Purpose DC/DC, LCD Supply 3, Non-Isolated Outputs Evaluation Board
