دیتاشیت ADL5323ACPZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADL5323
|
| حجم فایل |
198.201
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Frequency:
1.7GHz ~ 2.4GHz
-
P1dB:
27.3dBm ~ 28dBm
-
Gain:
18dB ~ 24dB
-
Noise Figure:
5dB
-
RF Type:
Cellular, CDMA2000, W-CDMA, GSM
-
Voltage - Supply:
4.75V ~ 5.25V
-
Current - Supply:
320mA
-
Test Frequency:
1.96GHz
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VFDFN Exposed Pad, CSP
-
Supplier Device Package:
8-LFCSP-VD (3x3)
-
Base Part Number:
ADL5323
-
detail:
RF Amplifier IC Cellular, CDMA2000, W-CDMA, GSM 1.7GHz ~ 2.4GHz 8-LFCSP-VD (3x3)
