TLC5943 Datasheet

TLC5943

Datasheet specifications

Datasheet's name TLC5943
File size 2525.866 KB
File type pdf
Number of pages 42

Download Datasheet TLC5943

Download Datasheet

Other documentations

TLC5943EVM-274 User Guide 27 pages

Technical specifications

  • Voltage - Input: 5V ~ 17V
  • Supplied Contents: Board(s)
  • Base Part Number: TLC594
  • Utilized IC / Part: TLC5943
  • Features: Dimmable
  • Part Status: Obsolete
  • Voltage - Output: -
  • Series: -
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 50mA
  • Outputs and Type: 16, Non-Isolated
  • Packaging: Box
  • detail: TLC5943 16, Non-Isolated Outputs LED Driver Evaluation Board
