- HMC849LP4CE
HMC849LP4CE Datasheet
Datasheet specifications
| Datasheet's name | HMC849LP4CE |
|---|---|
| File size | 414.204 KB |
| File type | |
| Number of pages | 8 |
Download Datasheet HMC849LP4CE |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- RF Type: General Purpose
- Topology: Absorptive
- Circuit: SPDT
- Frequency Range: DC ~ 6GHz
- Isolation: 52dB
- Insertion Loss: 1.7dB
- Test Frequency: 6GHz
- P1dB: 35dBm
- IIP3: 52dBm
- Features: -
- Impedance: 50Ohm
- Voltage - Supply: -
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 16-VQFN Exposed Pad
- Supplier Device Package: 16-QFN (4x4)
- Base Part Number: HMC849
- detail: RF Switch IC General Purpose SPDT 6GHz 50Ohm 16-QFN (4x4)
