دیتاشیت MCP1602-330I/MS

مشخصات دیتاشیت

دانلود دیتاشیت MCP1602 Datasheet	MCP1602 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Microchip Tech MCP1602-330I/MS
Output Type: Fixed
Input Voltage: 2.7V~5.5V
Output Voltage: 3.3V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 500mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-8
Manufacturer: Microchip Tech
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.7V
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Current - Output: 500mA
Frequency - Switching: 2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package: 8-MSOP
Base Part Number: MCP1602
detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 500mA 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
