دیتاشیت TC4426ACPA

TC4426ACPA

مشخصات دیتاشیت

نام دیتاشیت TC4426ACPA
حجم فایل 69.311 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

TC4426ACPA

دانلود دیتاشیت

سایر مستندات

Analog and Interface Product Guide 76 pages

TC4428AEOA 26 pages

TC4426A-28A 26 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Microchip Tech TC4426ACPA
  • Fall Time: 25ns
  • Load Type: MOSFET
  • Rise Time: 25ns
  • Supply Voltage: 4.5V~18V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: 0°C~+70°C@(Ta)
  • Peak Output Current(sink): 1.5A
  • Peak Output Current(source): 1.5A
  • Package: PDIP-8-300mil
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Current - Peak Output (Source, Sink): 1.5A, 1.5A
  • Input Type: Inverting
  • Rise / Fall Time (Typ): 25ns, 25ns
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC4426A
  • detail: Low-Side Gate Driver IC Inverting 8-PDIP
