دیتاشیت AD7224KRZ-1REEL

AD7224

مشخصات دیتاشیت

نام دیتاشیت AD7224
حجم فایل 234.359 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت AD7224

AD7224 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Number of Bits: 8
  • Number of D/A Converters: 1
  • Settling Time: 20µs
  • Output Type: Voltage - Buffered
  • Differential Output: No
  • Data Interface: Parallel
  • Reference Type: External
  • Voltage - Supply, Analog: 11.4V ~ 16.5V, ±5V
  • Voltage - Supply, Digital: 14.25V ~ 15.75V
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Architecture: R-2R
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 20-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 20-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: AD7224
  • detail: 8 Bit Digital to Analog Converter 1 20-SOIC
