MIC5283 Series دیتاشیت

MIC5283 Series

مشخصات دیتاشیت

نام دیتاشیت MIC5283 Series
حجم فایل 978.352 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت MIC5283 Series

دانلود دیتاشیت

سایر مستندات

MIC5283-5.0YML-TR 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Microchip Tech MIC5283-3.3YME
  • Output Current: 150mA
  • Output Voltage: 3.3V
  • Dropout Voltage: 2.8V@(150mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 120V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 14uA
  • Package: SOIC-8-EP
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 120V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 2.8V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 14µA
  • PSRR: 70dB ~ 65dB (100Hz ~ 100kHz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: MIC5283
  • detail: Linear Voltage Regulator IC 1 Output 150mA 8-SOIC-EP
