دیتاشیت MCP3301-BI/MS

MCP3301

مشخصات دیتاشیت

نام دیتاشیت MCP3301
حجم فایل 1014.458 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت MCP3301

MCP3301 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 13
  • Sampling Rate (Per Second): 100k
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: SPI
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: MCP3301
  • detail: 13 Bit Analog to Digital Converter 1 Input 1 SAR 8-MSOP
