- Datasheet ADP5520
ADP5520ACPZ-R7 Datasheet
Datasheet specifications
| Datasheet's name | ADP5520 |
|---|---|
| File size | 1243.53 KB |
| File type | |
| Number of pages | 38 |
Download Datasheet ADP5520 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Type: DC DC Regulator
- Topology: Step-Up (Boost)
- Internal Switch(s): Yes
- Number of Outputs: 4
- Voltage - Supply (Min): 2.7V
- Voltage - Supply (Max): 5.5V
- Voltage - Output: 27V
- Current - Output / Channel: 14mA, 30mA
- Frequency: -
- Dimming: I²C
- Applications: Backlight
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 24-VFQFN Exposed Pad, CSP
- Supplier Device Package: 24-LFCSP-VQ (4x4)
- Base Part Number: ADP5520
- detail: LED Driver IC 4 Output DC DC Regulator Step-Up (Boost) I²C Dimming 14mA, 30mA 24-LFCSP-VQ (4x4)
