دیتاشیت APT106N60B2C6
مشخصات دیتاشیت
| نام دیتاشیت |
APT106N60B2C6
|
| حجم فایل |
783.94
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
Microchip Technology
-
Series:
CoolMOS™
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
600V
-
Current - Continuous Drain (Id) @ 25°C:
106A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
35mOhm @ 53A, 10V
-
Vgs(th) (Max) @ Id:
3.5V @ 3.4mA
-
Gate Charge (Qg) (Max) @ Vgs:
308nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
8390pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
833W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
T-MAX™ [B2]
-
Package / Case:
TO-247-3 Variant
-
detail:
N-Channel 600V 106A (Tc) 833W (Tc) Through Hole T-MAX™ [B2]
