LP3855-ADJ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LP3855-ADJ
|
|
حجم فایل
|
2661.15
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
Control Features:
Enable
-
Base Part Number:
LP3855
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Current - Supply (Max):
10mA
-
Part Status:
Obsolete
-
Current - Output:
1.5A
-
PSRR:
73dB ~ 57dB (120Hz)
-
Series:
-
-
Voltage - Output (Min/Fixed):
1.23V
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
3mA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
0.435V @ 1.5A
-
Operating Temperature:
-40°C ~ 125°C
-
Supplier Device Package:
DDPAK/TO-263-5
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
7V
-
Output Type:
Adjustable
-
Packaging:
Tube
-
Voltage - Output (Max):
6.6V
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A DDPAK/TO-263-5
