دیتاشیت ADG749BKSZ-REEL7

ADG749

مشخصات دیتاشیت

نام دیتاشیت ADG749
حجم فایل 300.006 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADG749

ADG749 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: SPDT
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 1
  • On-State Resistance (Max): 5Ohm
  • Channel-to-Channel Matching (ΔRon): -
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): 7ns, 3ns (Typ)
  • -3db Bandwidth: 200MHz
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 7pF
  • Current - Leakage (IS(off)) (Max): 250pA
  • Crosstalk: -82dB @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 6-TSSOP, SC-88, SOT-363
  • Supplier Device Package: SC-70-6
  • Base Part Number: ADG749
  • detail: 1 Circuit IC Switch 2:1 5Ohm SC-70-6
