دیتاشیت ADG1611BCPZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | ADG1611-13 |
|---|---|
| حجم فایل | 488.704 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت ADG1611-13 |
ADG1611-13 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG1611BCPZ-REEL7
- Turn-on time: 156ns
- Turn-off time: 87ns
- Supply Voltage: 3.3V~16V
- Switch Circuit: SPST(SPST)-Normally closed
- Number of Channels: 4
- On-State Resistance (Max): 1.1Ω
- Package: LFCSP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- Channel-to-Channel Matching (ΔRon): 30mOhm
- Voltage - Supply, Single (V+): 3.3V ~ 16V
- Voltage - Supply, Dual (V±): ±3.3V ~ 8V
- Switch Time (Ton, Toff) (Max): 156ns, 87ns
- -3db Bandwidth: 38MHz
- Charge Injection: 170pC
- Channel Capacitance (CS(off), CD(off)): 60pF, 60pF
- Current - Leakage (IS(off)) (Max): 300pA
- Crosstalk: -110dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-VQFN Exposed Pad, CSP
- Supplier Device Package: 16-LFCSP-VQ (4x4)
- Base Part Number: ADG1611
- detail: 4 Circuit IC Switch 1:1 1.1Ohm 16-LFCSP-VQ (4x4)
