PCA9534PW,118 Datasheet

PCA9534

Datasheet specifications

Datasheet's name PCA9534
File size 264.061 KB
File type pdf
Number of pages 27

Download Datasheet PCA9534

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/I/O Expanders
  • Datasheet: NXP Semicon PCA9534PW,118
  • Interface: I2C;SMBus
  • Output Type: Push-pull
  • Number of I/O: 8
  • Supply Voltage: 2.3V~5.5V
  • Clock Frequency: 400kHz
  • Interrupt Output: 有中断输出
  • Output Sink Current: 25mA
  • Operating Temperature: -40°C~+85°C
  • Output Source current: 10mA
  • Package: TSSOP-16
  • Manufacturer: NXP Semicon
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Features: POR
  • Current - Output Source/Sink: 10mA, 25mA
  • Voltage - Supply: 2.3V ~ 5.5V
  • Mounting Type: Surface Mount
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-TSSOP
  • Base Part Number: PCA95
  • detail: I/O Expander 8 I²C, SMBus 400kHz 16-TSSOP
