APTC60DSKM24T3G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
APTC60DSKM24T3G
|
|
حجم فایل
|
369.489
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
CoolMOS™
-
Packaging:
Tray
-
Part Status:
Active
-
FET Type:
2 N Channel (Dual Buck Chopper)
-
FET Feature:
Super Junction
-
Drain to Source Voltage (Vdss):
600V
-
Current - Continuous Drain (Id) @ 25°C:
95A
-
Rds On (Max) @ Id, Vgs:
24mOhm @ 47.5A, 10V
-
Vgs(th) (Max) @ Id:
3.9V @ 5mA
-
Gate Charge (Qg) (Max) @ Vgs:
300nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
14400pF @ 25V
-
Power - Max:
462W
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
SP3
-
Supplier Device Package:
SP3
-
detail:
Mosfet Array 2 N Channel (Dual Buck Chopper) 600V 95A 462W Chassis Mount SP3
