LM5002SD دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LM5002	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Package / Case: 8-WDFN Exposed Pad
Function: Step-Up, Step-Up/Step-Down
Output Configuration: Positive, Isolation Capable
Topology: Boost, Flyback, Forward Converter, SEPIC
Base Part Number: LM5002
Packaging: Cut Tape (CT)
Operating Temperature: -40°C ~ 125°C (TJ)
Frequency - Switching: 50kHz ~ 1.5MHz
Supplier Device Package: 8-WSON (4x4)
Part Status: Obsolete
Current - Output: 400mA (Switch)
Number of Outputs: 1
Series: -
Manufacturer: Texas Instruments
Voltage - Input (Max): 75V
Synchronous Rectifier: No
Voltage - Output (Min/Fixed): 3.1V
Voltage - Input (Min): 3.1V
Mounting Type: Surface Mount
Voltage - Output (Max): 76V (Switch)
Output Type: Adjustable
detail: Boost, Flyback, Forward Converter, SEPIC Switching Regulator IC Positive, Isolation Capable Adjustable 3.1V 1 Output 400mA (Switch) 8-WDFN Exposed Pad
