BFU520WX دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
BFU520W
|
|
حجم فایل
|
303.476
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
NXP Semicon BFU520WX
-
Transistor Type:
NPN
-
Operating Temperature:
-40°C~+150°C@(Tj)
-
Collector Current (Ic):
5mA
-
Power Dissipation (Pd):
450mW
-
Transition Frequency (fT):
10GHz
-
DC Current Gain (hFE@Ic,Vce):
95@5mA,8V
-
Collector Cut-Off Current (Icbo):
1nA
-
Collector-Emitter Breakdown Voltage (Vceo):
12V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
-
-
Package:
SOT-323-3
-
Manufacturer:
NXP Semicon
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Collector Emitter Breakdown (Max):
12V
-
Frequency - Transition:
10GHz
-
Noise Figure (dB Typ @ f):
0.6dB @ 900MHz
-
Gain:
18.5dB
-
Power - Max:
450mW
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
60 @ 5mA, 8V
-
Current - Collector (Ic) (Max):
30mA
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-70, SOT-323
-
Supplier Device Package:
SOT-323-3
-
Base Part Number:
BFU52
-
detail:
RF Transistor NPN 12V 30mA 10GHz 450mW Surface Mount SOT-323-3
