MK22FN128VLH10 دیتاشیت

MK22FN128VLH10

مشخصات دیتاشیت

نام دیتاشیت MK22FN128VLH10
حجم فایل 93.861 کیلوبایت
نوع فایل pdf
تعداد صفحات 74

مشاهده دیتاشیت MK22FN128VLH10

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-M4
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 24KB
  • Watchdog: Yes
  • ADC (Bit): 16bit
  • DAC (Bit): 12bit
  • Datasheet: NXP Semicon MK22FN128VLH10
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 100MHz
  • GPIO Ports Number: 40
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: DMA;Low-VoltageDetect;WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 128KB
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: 1.71V~3.6V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: LQFP-64(10x10)
  • Manufacturer: NXP Semicon
  • Series: Kinetis K20
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-M4
  • Core Size: 32-Bit
  • Speed: 100MHz
  • Connectivity: I²C, IrDA, SPI, UART/USART, USB, USB OTG
  • Peripherals: DMA, I²S, LVD, POR, PWM, WDT
  • Number of I/O: 40
  • Program Memory Size: 128KB (128K x 8)
  • EEPROM Size: -
  • Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
  • Data Converters: A/D 22x16b; D/A 1x12b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 64-LQFP
  • Supplier Device Package: 64-LQFP (10x10)
  • Base Part Number: MK22
  • detail: ARM® Cortex®-M4 Kinetis K20 Microcontroller IC 32-Bit 100MHz 128KB (128K x 8) FLASH 64-LQFP (10x10)
