LX4F230H5QRFIGB0 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LX4F230H5QR Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Voltage - Supply (Vcc/Vdd): 1.08V ~ 3.63V
Speed: 80MHz
EEPROM Size: 2K x 8
Data Converters: A/D 12x12b
Base Part Number: LX4F230H5
Package / Case: 64-LQFP
Program Memory Type: FLASH
Series: Stellaris® ARM® Cortex®-M4F 230
Number of I/O: 43
RAM Size: 32K x 8
Mounting Type: Surface Mount
Part Status: Discontinued at Digi-Key
Program Memory Size: 256KB (256K x 8)
Core Size: 32-Bit
Operating Temperature: -40°C ~ 85°C (TA)
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
Supplier Device Package: 64-LQFP (10x10)
Oscillator Type: Internal
Core Processor: ARM® Cortex®-M4
Manufacturer: Texas Instruments
Connectivity: CANbus, I²C, IrDA, LINbus, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Packaging: Tray
detail: ARM® Cortex®-M4 Stellaris® ARM® Cortex®-M4F 230 Microcontroller IC 32-Bit 80MHz 256KB (256K x 8) FLASH 64-LQFP (10x10)
