- دیتاشیت Digital Pot Design Guide
Digital Pot Design Guide دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | Digital Pot Design Guide |
|---|---|
| حجم فایل | 4581.524 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت Digital Pot Design Guide |
دانلود دیتاشیت |
|---|
سایر مستندات
MCP443x/5x 94 pages
MCP4451-104E/ST 94 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital Potentiometers
- Datasheet: Microchip Tech MCP4451-502E/ML
- Precision: ±20%
- Interface Type: I2C
- Number of Taps: 257
- Supply Voltage: 1.8V~5.5V
- Number of Channels: 4
- Operating Temperature: -40°C~+125°C
- Resistance Value (Ohms): 5kΩ
- Temperature Coefficient (Typ): 150ppm/°C
- Package: QFN-20
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Taper: Linear
- Configuration: Potentiometer
- Number of Circuits: 4
- Resistance (Ohms): 5k
- Interface: I²C
- Memory Type: Volatile
- Voltage - Supply: 1.8V ~ 5.5V
- Features: Mute, Selectable Address
- Tolerance: ±20%
- Mounting Type: Surface Mount
- Supplier Device Package: 20-QFN (4x4)
- Package / Case: 20-VFQFN Exposed Pad
- Resistance - Wiper (Ohms) (Typ): 75
- Base Part Number: MCP4451
- detail: Digital Potentiometer 5k Ohm 4 Circuit 257 Taps I²C Interface 20-QFN (4x4)
