MPX53GP دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MPX53GP	دانلود دیتاشیت

Manufacturer: NXP USA Inc.
Series: MPX53
Part Status: Active
Applications: Board Mount
Pressure Type: Vented Gauge
Operating Pressure: 7.25PSI (50kPa)
Output Type: Wheatstone Bridge
Output: 0 mV ~ 60 mV (3V)
Accuracy: -0.6% ~ 0.4%
Voltage - Supply: 3V ~ 6V
Port Size: Male - 0.19" (4.93mm) Tube
Port Style: Barbed
Features: -
Termination Style: PC Pin
Maximum Pressure: 25.38PSI (175kPa)
Operating Temperature: -40°C ~ 125°C
Package / Case: 4-SIP Module
Supplier Device Package: -
Base Part Number: MPX53
detail: Pressure Sensor 7.25PSI (50kPa) Vented Gauge Male - 0.19" (4.93mm) Tube 0 mV ~ 60 mV (3V) 4-SIP Module
