DSP56F801FA60E دیتاشیت

DSP56F801

مشخصات دیتاشیت

نام دیتاشیت DSP56F801
حجم فایل 743.638 کیلوبایت
نوع فایل pdf
تعداد صفحات 48

مشاهده دیتاشیت DSP56F801

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • EEPROM: -
  • CPU Core: Other series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 2KB
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: NXP Semicon DSP56F801FA60E
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 60MHz
  • GPIO Ports Number: 11
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: -
  • Program Storage Size: 16KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 3V~3.6V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+85°C
  • Secure Digital Input and Output: -
  • Package: LQFP-48(7x7)
  • Manufacturer: NXP Semicon
  • Series: 56F8xx
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: 56800
  • Core Size: 16-Bit
  • Speed: 60MHz
  • Connectivity: SCI, SPI
  • Peripherals: POR, PWM, WDT
  • Number of I/O: 11
  • Program Memory Size: 16KB (8K x 16)
  • EEPROM Size: -
  • Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
  • Data Converters: A/D 8x12b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 48-LQFP
  • Supplier Device Package: 48-LQFP (7x7)
  • Base Part Number: DSP56
  • detail: 56800 56F8xx Microcontroller IC 16-Bit 60MHz 16KB (8K x 16) FLASH 48-LQFP (7x7)
