MCF52221CAE66 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MCF52221CAE66	دانلود دیتاشیت

RoHS: true
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: NXP Semicon MCF52221CAE66
CPU Maximum Speed: 66MHz
GPIO Ports Number: 56
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Direct Memory Access: Yes
Program Storage Size: 128KB
Universal Serial Bus: Yes
Operating Voltage Range: 3V~3.6V
Operating Temperature Range: -40°C~+85°C
Package: LQFP-64(10x10)
Manufacturer: NXP Semicon
Series: MCF5222x
Packaging: Tray
Part Status: Active
Core Processor: Coldfire V2
Core Size: 32-Bit
Speed: 66MHz
Connectivity: I²C, SPI, UART/USART, USB OTG
Peripherals: DMA, LVD, POR, PWM, WDT
Number of I/O: 56
Program Memory Size: 128KB (128K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 16K x 8
Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
Data Converters: A/D 8x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 64-LQFP
Supplier Device Package: 64-LQFP (10x10)
Base Part Number: MCF52
detail: Coldfire V2 MCF5222x Microcontroller IC 32-Bit 66MHz 128KB (128K x 8) FLASH 64-LQFP (10x10)
