MCIMX6G2AVM05AB دیتاشیت

MCIMX6G2AVM05AB

مشخصات دیتاشیت

نام دیتاشیت MCIMX6G2AVM05AB
حجم فایل 92.323 کیلوبایت
نوع فایل pdf
تعداد صفحات 132

دانلود دیتاشیت MCIMX6G2AVM05AB

دانلود دیتاشیت

سایر مستندات

MCIMX6Gx Automotive Appl Processors 119 pages

مشخصات فنی

  • CAN: -
  • I2C: 4
  • I2S: -
  • SPI: 4
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM-ASeries
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 128KB
  • Watchdog: -
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: NXP Semicon MCIMX6G2AVM05AB
  • PWM (Bit): -
  • 8Bit Timer: -
  • LCD Module: Yes
  • LED Module: -
  • UART/USART: 8
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • Application Area: -
  • CPU Maximum Speed: 528MHz
  • GPIO Ports Number: -
  • Low-Voltage Detect: -
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: -
  • Peripheral/Function: 硬件加密;TRNG
  • Program Memory Type: -
  • Direct Memory Access: -
  • Program Storage Size: -
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: -
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+125°C
  • Secure Digital Input and Output: -
  • Package: MAPBGA-289
  • Manufacturer: NXP Semicon
  • Series: i.MX6UL
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-A7
  • Number of Cores/Bus Width: 1 Core, 32-Bit
  • Speed: 528MHz
  • Co-Processors/DSP: Multimedia; NEON™ SIMD
  • RAM Controllers: LPDDR2, DDR3, DDR3L
  • Graphics Acceleration: No
  • Display & Interface Controllers: LCD, LVDS
  • Ethernet: 10/100Mbps (2)
  • SATA: -
  • USB: USB 2.0 + PHY (2)
  • Voltage - I/O: 1.2V, 1.35V, 1.5V, 1.8V, 2.5V, 2.8V, 3.3V
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Security Features: ARM TZ, A-HAB, CAAM, CSU, SJC, SNVS
  • Package / Case: 289-LFBGA
  • Supplier Device Package: 289-MAPBGA (14x14)
  • Additional Interfaces: CAN, EBI/EMI, I²C, I²S, MMC/SD/SDIO, QSPI, SAI, SPI, SSI, S/PDIF, UART
  • Base Part Number: MCIMX6
  • detail: ARM® Cortex®-A7 Microprocessor IC i.MX6UL 1 Core, 32-Bit 528MHz 289-MAPBGA (14x14)
