دیتاشیت TEA1832TS/1X

TEA1832TS/1

مشخصات دیتاشیت

نام دیتاشیت TEA1832TS/1
حجم فایل 242.671 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت TEA1832TS/1

TEA1832TS/1 Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: GreenChip™ II
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Output Isolation: Isolated
  • Internal Switch(s): No
  • Voltage - Breakdown: -
  • Topology: Flyback
  • Voltage - Start Up: 22V
  • Voltage - Supply (Vcc/Vdd): 10.5V ~ 36V
  • Duty Cycle: 90%
  • Frequency - Switching: 36kHz ~ 130kHz
  • Fault Protection: Over Power, Over Temperature, Over Voltage, Short Circuit
  • Control Features: -
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Package / Case: SC-74, SOT-457
  • Supplier Device Package: 6-TSOP
  • Mounting Type: Surface Mount
  • Base Part Number: TEA183
  • detail: Converter Offline Flyback Topology 36kHz ~ 130kHz 6-TSOP
