S9S12ZVL32F0MLF دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | S9S12ZVL32F0MLF |
|---|---|
| حجم فایل | 30.256 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 44 |
دانلود دیتاشیت S9S12ZVL32F0MLF |
دانلود دیتاشیت |
|---|
سایر مستندات
S12ZVL Family Fact Sheet 1 pages
MC9S12ZVL Family Ref Manual, Datasheet 783 pages
مشخصات فنی
- RoHS: true
- CPU Core: Other series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit
- Datasheet: NXP Semicon S9S12ZVL32F0MLF
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 34
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 32KB
- Operating Voltage Range: 5.5V~18V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+125°C
- Package: LQFP-48
- Manufacturer: NXP Semicon
- Series: S12 MagniV
- Packaging: Tray
- Part Status: Active
- Core Processor: S12Z
- Core Size: 16-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, LINbus, SCI, SPI, UART/USART
- Peripherals: LVD, POR, PWM, WDT
- Number of I/O: 34
- Program Memory Size: 32KB (32K x 8)
- Program Memory Type: FLASH
- EEPROM Size: 128 x 8
- RAM Size: 1K x 8
- Voltage - Supply (Vcc/Vdd): 5.5V ~ 18V
- Data Converters: A/D 10x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-LQFP
- Supplier Device Package: 48-LQFP (7x7)
- Base Part Number: S9S12
- detail: S12Z S12 MagniV Microcontroller IC 16-Bit 32MHz 32KB (32K x 8) FLASH 48-LQFP (7x7)
