دیتاشیت MC56F8256VLF

مشخصات دیتاشیت

دانلود دیتاشیت MC56F825x/824x Product Brief	MC56F825x/824x Product Brief Datasheet

RoHS: true
Category: Single Chip Microcomputer/Microcontroller/Digital Signal Processors / Controllers (DSPs/DSCs)
Datasheet: NXP Semicon MC56F8256VLF
FLASH Size: 64KB
GPIO Ports Number: 39
Supply Voltage Range: 3V~3.6V
Operating Temperature Range: -40°C~+105°C
Package: LQFP-48(7x7)
Manufacturer: NXP Semicon
Series: 56F8xxx
Packaging: Tray
Part Status: Active
Core Processor: 56800E
Core Size: 16-Bit
Speed: 60MHz
Connectivity: CANbus, I²C, LINbus, SCI, SPI
Peripherals: LVD, POR, PWM, WDT
Number of I/O: 39
Program Memory Size: 64KB (32K x 16)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 4K x 16
Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
Data Converters: A/D 10x12b; D/A 1x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 105°C (TA)
Mounting Type: Surface Mount
Package / Case: 48-LQFP
Supplier Device Package: 48-LQFP (7x7)
Base Part Number: MC56
detail: 56800E 56F8xxx Microcontroller IC 16-Bit 60MHz 64KB (32K x 16) FLASH 48-LQFP (7x7)
