PMBFJ177,215 دیتاشیت

PMBFJ177,215

مشخصات دیتاشیت

نام دیتاشیت PMBFJ177,215
حجم فایل 37.519 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت PMBFJ177,215

دانلود دیتاشیت

سایر مستندات

PMBFJ174-177 10 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Nexperia PMBFJ177,215
  • Power Dissipation (Pd): 300mW
  • Drain Source Voltage (Vdss): 30V
  • Continuous Drain Current (Id): 50mA
  • Gate Threshold Voltage (Vgs(th)@Id): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): -
  • Package: SOT-23(TO-236)
  • Manufacturer: Nexperia
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Last Time Buy
  • FET Type: P-Channel
  • Voltage - Breakdown (V(BR)GSS): 30V
  • Drain to Source Voltage (Vdss): 30V
  • Current - Drain (Idss) @ Vds (Vgs=0): 1.5mA @ 15V
  • Voltage - Cutoff (VGS off) @ Id: 800mV @ 10nA
  • Input Capacitance (Ciss) (Max) @ Vds: 8pF @ 10V (VGS)
  • Resistance - RDS(On): 300 Ohms
  • Power - Max: 300mW
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23 (TO-236AB)
  • Base Part Number: PMBFJ1
  • detail: JFET P-Channel 30V 300mW Surface Mount SOT-23 (TO-236AB)
