- LMV7235, LMV7239 Datasheet
LMV7239 MWC Datasheet
Datasheet specifications
| Datasheet's name | LMV7235, LMV7239 Datasheet |
|---|---|
| File size | 1652.27 KB |
| File type | |
| Number of pages | 31 |
Download Datasheet LMV7235, LMV7239 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- CMRR, PSRR (Typ): 67dB CMRR, 85dB PSRR
- Voltage - Supply, Single/Dual (±): 2.7V ~ 5.5V
- Base Part Number: LMV723
- Packaging: Tray
- Type: General Purpose
- Package / Case: Die
- Current - Input Bias (Max): 0.4µA @ 5V
- Supplier Device Package: Wafersale
- Mounting Type: Surface Mount
- Part Status: Obsolete
- Current - Quiescent (Max): 95µA
- Operating Temperature: -40°C ~ 85°C
- Series: -
- Manufacturer: Texas Instruments
- Hysteresis: -
- Voltage - Input Offset (Max): 6mV @ 5V
- Current - Output (Typ): -
- Number of Elements: 1
- Propagation Delay (Max): 62ns
- Output Type: Push-Pull, Rail-to-Rail
- detail: Comparator General Purpose Push-Pull, Rail-to-Rail Wafersale
