دیتاشیت PCA9554PW/Q900,118
مشخصات دیتاشیت
| نام دیتاشیت | PCA9554(A) |
|---|---|
| حجم فایل | 610.798 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت PCA9554(A) |
PCA9554(A) Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/I/O Expanders
- Datasheet: NXP Semicon PCA9554PW/Q900,118
- Interface: I2C;SMBus
- Output Type: Push-pull
- Supply Voltage: 2.3V~5.5V
- Clock Frequency: 400kHz
- Interrupt Output: 有中断输出
- Output Sink Current: 25mA
- Operating Temperature: -40°C~+85°C
- Output Source current: 10mA
- Package: TSSOP-16
- Manufacturer: NXP Semicon
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of I/O: 8
- Features: POR
- Current - Output Source/Sink: 10mA, 25mA
- Voltage - Supply: 2.3V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: PCA95
- detail: I/O Expander 8 I²C, SMBus 400kHz 16-TSSOP
