KMI23/2Z Datasheet
Datasheet specifications
| Datasheet's name | KMI23/2Z, KMI25/4 |
|---|---|
| File size | 355.085 KB |
| File type | |
| Number of pages | 26 |
Download Datasheet KMI23/2Z, KMI25/4 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: NXP USA Inc.
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- For Measuring: Rotary Position
- Technology: Magnetoresistive
- Rotation Angle - Electrical, Mechanical: -
- Linear Range: -
- Output: Analog Voltage
- Output Signal: Clockwise Increase
- Actuator Type: External Magnet, Not Included
- Linearity: -
- Resistance Tolerance: -
- Mounting Type: Through Hole
- Termination Style: PC Pin
- Operating Temperature: -40°C ~ 150°C
- Package / Case: 3-SIP Module
- Supplier Device Package: 3-SIP
- Base Part Number: KMI23
- detail: Magnetoresistive Sensor Rotary Position External Magnet, Not Included PC Pin
