LPC2214FBD144/01K Datasheet
Datasheet specifications
| Datasheet's name | LPC221x |
|---|---|
| File size | 345.282 KB |
| File type | |
| Number of pages | 47 |
Download Datasheet LPC221x |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- CPU Core: ARMOther series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit
- Datasheet: NXP Semicon LPC2214FBD144/01K
- CPU Maximum Speed: 60MHz
- GPIO Ports Number: 112
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 256KB
- Operating Voltage Range: 1.65V~1.95V
- Operating Temperature Range: -40°C~+85°C
- Package: LQFP-144(20x20)
- Manufacturer: NXP Semicon
- Series: LPC2200
- Part Status: Active
- Core Processor: ARM7®
- Core Size: 16/32-Bit
- Speed: 60MHz
- Connectivity: EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART
- Peripherals: POR, PWM, WDT
- Number of I/O: 112
- Program Memory Size: 256KB (256K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 16K x 8
- Voltage - Supply (Vcc/Vdd): 1.65V ~ 1.95V
- Data Converters: A/D 8x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 144-LQFP
- Supplier Device Package: 144-LQFP (20x20)
- Base Part Number: LPC22
- detail: ARM7® LPC2200 Microcontroller IC 16/32-Bit 60MHz 256KB (256K x 8) FLASH 144-LQFP (20x20)
