دیتاشیت SGTL5000XNLA3R2
مشخصات دیتاشیت
| نام دیتاشیت | SGTL5000 Datasheet |
|---|---|
| حجم فایل | 3644.072 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 68 |
دانلود دیتاشیت SGTL5000 Datasheet |
SGTL5000 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Audio Interface ICs
- Datasheet: NXP Semicon SGTL5000XNLA3R2
- Interface: I2C;serial;SPI
- Operating Temperature: -40°C~+85°C
- Package: QFN-20-EP(3x3)
- Manufacturer: NXP Semicon
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Stereo Audio
- Data Interface: I²C, Serial, SPI™
- Resolution (Bits): -
- Number of ADCs / DACs: 1 / 1
- Sigma Delta: No
- S/N Ratio, ADCs / DACs (db) Typ: 90 / 100
- Dynamic Range, ADCs / DACs (db) Typ: -
- Voltage - Supply, Analog: 1.62V ~ 3.6V
- Voltage - Supply, Digital: 1.1V ~ 2V, 1.62V ~ 3.6V
- Mounting Type: Surface Mount
- Package / Case: 20-UFQFN Exposed Pad
- Supplier Device Package: 20-QFN-EP (3x3)
- Base Part Number: SGTL5
- detail: Stereo Audio Interface I²C, Serial, SPI™ 20-QFN-EP (3x3)
