دیتاشیت SG1843J-DESC
مشخصات دیتاشیت
| نام دیتاشیت |
SGx84x Series
|
| حجم فایل |
733.471
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Microchip Tech SG1843J-DESC
-
Output Type:
-
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Operating Temperature:
-55°C~+125°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOP-14
-
Manufacturer:
Microchip Tech
-
Series:
Military, MIL-STD-883B
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
7.6V ~ 30V
-
Frequency - Switching:
1Hz ~ 500kHz
-
Duty Cycle (Max):
95%
-
Synchronous Rectifier:
No
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Control Features:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
14-SOIC
-
Notification:
QPL or Military Specs are for reference only. Parts are not for military use. See Terms and Conditions.
-
detail:
Buck Regulator Positive Output Step-Down DC-DC Controller IC 14-SOIC
