TPS78633DCQR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS78633DCQR |
|---|---|
| حجم فایل | 101.266 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت TPS78633DCQR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS786xx Datasheet 36 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS78633DCQR
- Output Type: Fixed
- Output Current: 1.5A
- Output Voltage: 3.3V
- Dropout Voltage: 510mV@(1.5A)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 385uA
- Power Supply Rejection Ratio (PSRR): 59dB@(100Hz),32dB@(100kHz)
- Package: SOT-223-6
- Manufacturer: Texas Instruments
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Package / Case: SOT-223-6
- Output Configuration: Positive
- Current - Output: 1.5A
- Base Part Number: TPS786
- Control Features: Enable
- Supplier Device Package: SOT-223-6
- Part Status: Active
- Voltage Dropout (Max): 0.51V @ 1.5A
- PSRR: 59dB ~ 32dB (100Hz ~ 100kHz)
- Series: -
- Voltage - Input (Max): 5.5V
- Number of Regulators: 1
- Voltage - Output (Min/Fixed): 3.3V
- Current - Quiescent (Iq): 385µA
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Voltage - Output (Max): -
- detail: Linear Voltage Regulator IC 1 Output 1.5A SOT-223-6
