دیتاشیت SN74LS73AN

مشخصات دیتاشیت

دانلود دیتاشیت SN5473, SN54LS73A, SN7473, SN74LS73A	SN5473, SN54LS73A, SN7473, SN74LS73A Datasheet

RoHS: true
Type: JK-Type
Series: 74LS
Category: Logic ICs/Flip Flops
Function: Reset
Datasheet: Texas Instruments SN74LS73AN
Output Type: 互补型
Sink Current: 8mA
Trigger Type: 下降沿
Source Current: 400uA
Supply Voltage: 4.75V~5.25V
Clock Frequency: 45MHz
Number of Elements: 2
Operating Temperature: 0°C~+70°C
Quiescent Current (Iq): 6mA
Maximum Propagation Delay: 20ns@5V,45pF
Number of Bits per Element: 1
Package: PDIP-14
Manufacturer: Texas Instruments
Base Part Number: SN74LS73
Max Propagation Delay @ V, Max CL: 20ns @ 5V, 45pF
Current - Output High, Low: 400µA, 8mA
Supplier Device Package: 14-PDIP
Voltage - Supply: 4.75V ~ 5.25V
Part Status: Active
Package / Case: 14-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Current - Quiescent (Iq): 6mA
Packaging: Tube
detail: Flip Flop 2 Element JK Type 1 Bit Negative Edge 14-DIP (0.300", 7.62mm)
