دیتاشیت TPS82084SILT
مشخصات دیتاشیت
| نام دیتاشیت | TPS82084 Datasheet |
|---|---|
| حجم فایل | 1258.093 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت TPS82084 Datasheet |
TPS82084 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Power Modules
- Datasheet: Texas Instruments TPS82084SILT
- Package: USIP-8
- Manufacturer: Texas Instruments
- Control Features: -
- Approval Agency: -
- Base Part Number: TPS820
- Type: Non-Isolated PoL Module
- Package / Case: 8-LDFN Exposed Pad, Module
- Features: Adjustable Output
- Part Status: Active
- Number of Outputs: 1
- Series: MicroSip™
- Mounting Type: Surface Mount
- Voltage - Output 3: -
- Efficiency: -
- Size / Dimension: 0.12" L x 0.11" W x 0.05" H (3.0mm x 2.8mm x 1.3mm)
- Voltage - Input (Min): 2.5V
- Operating Temperature: -40°C ~ 125°C
- Supplier Device Package: 8-uSIP (3x2.8)
- Voltage - Output 1: 0.8 ~ 6V
- Voltage - Output 2: -
- Voltage - Input (Max): 6V
- Current - Output (Max): 2A
- Packaging: Cut Tape (CT)
- Voltage - Output 4: -
- Applications: ITE (Commercial)
- detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 6V 2A 2.5V - 6V Input
