دیتاشیت LP3878MRX-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP3878-ADJ Datasheet |
|---|---|
| حجم فایل | 1401.058 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت LP3878-ADJ Datasheet |
LP3878-ADJ Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3878MRX-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 800mA
- Output Voltage: 1V~5.5V
- Dropout Voltage: 1.1V@(800mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 16V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 1.5mA
- Power Supply Rejection Ratio (PSRR): 60dB@(1kHz)
- Package: SOP-8
- Manufacturer: Texas Instruments
- Control Features: Enable
- Base Part Number: LP3878
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- Current - Supply (Max): 15mA
- Part Status: Active
- Current - Output: 800mA
- PSRR: 60dB (1kHz)
- Series: -
- Voltage - Output (Min/Fixed): 1V
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Current - Quiescent (Iq): 1.5mA
- Output Configuration: Positive
- Voltage Dropout (Max): 1.1V @ 800mA
- Supplier Device Package: 8-SO PowerPad
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Input (Max): 16V
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): 5.5V
- detail: Linear Voltage Regulator IC 1 Output 800mA 8-SO PowerPad
