MC56F8245VLD دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC56F8245VLD |
|---|---|
| حجم فایل | 116.523 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 88 |
دانلود دیتاشیت MC56F8245VLD |
دانلود دیتاشیت |
|---|
سایر مستندات
MC56F825x/824x Product Brief 14 pages
MC56F82xx Fact Sheet 2 pages
MC56F825x,824x Ref Manual 629 pages
MC56F825x/MC56F824x Errata 4 pages
مشخصات فنی
- RoHS: true
- EEPROM: 24KB
- CPU Core: -
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: NXP Semicon MC56F8245VLD
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 60MHz
- GPIO Ports Number: 35
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: Low-VoltageDetect;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 24KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 3V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: LQFP-44(10x10)
- Manufacturer: NXP Semicon
- Series: 56F8xxx
- Packaging: Tray
- Part Status: Active
- Core Processor: 56800E
- Core Size: 16-Bit
- Speed: 60MHz
- Connectivity: CANbus, I²C, LINbus, SCI, SPI
- Peripherals: LVD, POR, PWM, WDT
- Number of I/O: 35
- Program Memory Size: 48KB (24K x 16)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
- Data Converters: A/D 8x12b; D/A 1x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 44-LQFP
- Supplier Device Package: 44-LQFP (10x10)
- Base Part Number: MC56
- detail: 56800E 56F8xxx Microcontroller IC 16-Bit 60MHz 48KB (24K x 16) FLASH 44-LQFP (10x10)
