DCP020505P دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DCP020505P
|
|
حجم فایل
|
93.677
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
33
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Datasheet:
Texas Instruments DCP020505P
-
Output Power:
2W
-
Output Channel:
1
-
Output Voltage:
5V
-
Input Voltage(DC):
4.5V~5.5V
-
Output Current (Max):
400mA
-
Conversion Efficiency:
80%
-
Package:
PDIP-7
-
Manufacturer:
Texas Instruments
-
Control Features:
-
-
Base Part Number:
DCP0205
-
Type:
Isolated Module
-
Package / Case:
14-DIP (0.300", 7.62mm), 7 Leads
-
Power (Watts):
2W
-
Features:
OTP
-
Part Status:
Active
-
Number of Outputs:
1
-
Series:
DCP02 (2W)
-
Mounting Type:
Through Hole
-
Voltage - Output 3:
-
-
Efficiency:
80%
-
Size / Dimension:
0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm)
-
Voltage - Input (Min):
4.5V
-
Operating Temperature:
-40°C ~ 85°C
-
Voltage - Isolation:
1kV
-
Supplier Device Package:
7-PDIP
-
Voltage - Output 1:
5V
-
Voltage - Output 2:
-
-
Voltage - Input (Max):
5.5V
-
Current - Output (Max):
400mA
-
Packaging:
Tube
-
Applications:
ITE (Commercial)
-
detail:
Isolated Module DC DC Converter 1 Output 5V 400mA 4.5V - 5.5V Input
