DCH010505SN7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DCH010505SN7
|
|
حجم فایل
|
72.128
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Function:
-
-
Datasheet:
Texas Instruments DCH010505SN7
-
Output Power:
1W
-
Output Channel:
1
-
Output Voltage:
5V
-
Conversion Type:
DC-DC
-
Input Voltage(DC):
4.5V~5.5V
-
Insulated Voltage:
3kV
-
Output Current (Max):
200mA
-
Conversion Efficiency:
72%
-
Package:
Plugin
-
Manufacturer:
Texas Instruments
-
Base Part Number:
DCH010505
-
Type:
Isolated Module
-
Package / Case:
7-SIP Module, 4 Leads
-
Power (Watts):
1W
-
Features:
-
-
Part Status:
Active
-
Number of Outputs:
1
-
Series:
DCH01 (1W)
-
Mounting Type:
Through Hole
-
Voltage - Output 3:
-
-
Efficiency:
72%
-
Size / Dimension:
0.77" L x 0.30" W x 0.40" H (19.6mm x 7.6mm x 10.2mm)
-
Voltage - Input (Min):
4.5V
-
Operating Temperature:
-40°C ~ 85°C
-
Voltage - Isolation:
3kV
-
Voltage - Output 1:
5V
-
Voltage - Output 2:
-
-
Voltage - Input (Max):
5.5V
-
Current - Output (Max):
200mA
-
Packaging:
Tray
-
Applications:
ITE (Commercial)
-
detail:
Isolated Module DC DC Converter 1 Output 5V 200mA 4.5V - 5.5V Input
