MAX15006BATT+T دیتاشیت

MAX15006BATT+T

مشخصات دیتاشیت

نام دیتاشیت MAX15006BATT+T
حجم فایل 85.888 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت MAX15006BATT+T

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX15006,07 14 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX15006BATT+T
  • Output Current: 50mA
  • Output Voltage: 5V
  • Dropout Voltage: 0.525V@(50mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 40V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Quiescent Current (Ground Current): 17uA
  • Power Supply Rejection Ratio (PSRR): 66dB@(100Hz)
  • Package: DFN-6(3x3)
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Voltage Dropout (Max): 0.525V @ 50mA
  • PSRR: 66dB (100Hz)
  • Output Configuration: Positive
  • Current - Output: 50mA
  • Voltage - Output (Max): -
  • Supplier Device Package: 6-TDFN-EP (3x3)
  • Package / Case: 6-WDFN Exposed Pad
  • Packaging: Cut Tape (CT)
  • Voltage - Input (Max): 40V
  • Output Type: Fixed
  • Current - Supply (Max): 150µA
  • Protection Features: Over Temperature, Short Circuit
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Series: -
  • Voltage - Output (Min/Fixed): 5V
  • Current - Quiescent (Iq): 17µA
  • Control Features: -
  • Base Part Number: MAX15006
  • detail: Linear Voltage Regulator IC 1 Output 50mA 6-TDFN-EP (3x3)
